As an extension of Digi’s success with the ConnectCore6 system-on-module, they have announced the next iteration ConnectCore6+ with improved features and benefits…

The ConnectCore 6+ is a highly integrated system-on-module solution based on the NXP i.MX6Plus Cortex-A9 processor family. With processor speeds up to 1.2 GHz and fully pin-compatible quad-core variants, the ConnectCore 6+ offers a truly future-proof platform solution with scalable performance and pre-certified wireless 802.11a/b/g/n/ac and Bluetooth 4.2, including Bluetooth Low Energy, connectivity.

BENEFITS

  • Scalable Cortex-A9 multi-core performance
  • Independent Cortex-M0+/Cortex-M4 Microcontroller Assist™ subsystem
  • Cost-effective, reliable, low-profile surface-mount module form factor
  • Pre-certified 802.11a/b/g/n/ac and Bluetooth 4.2
  • Smart Power Management Architecture with PMIC
  • Yocto Project Linux software platform support
  • Dig TrustFence plus dedicated on-module security + authentication controller
  • Designed for long-term availability
  • No royalties, stable releases, full source code access, software support

Upgrade features and benefits from the ConnectCore 6

  • Extend the life of ConnectCore 6 applications
  • Same pinout
  • Addition of Secure element chip
  • Pre-certified dual-band 802.11ac
  • Bluetooth 4.2
  • Solid Shield
  • Improved performance and enhanced graphics of i.MX6Plus
  • And it will have coming very soon Android support
